19-0570; Rev 0; 5/06
MAX2043 Evaluation Kit
General Description
Features
The MAX2043 evaluation kit (EV kit) simplifies the evalu-
ation of the MAX2043 UMTS/WCDMA, DCS, PCS, and
WiMAX base-station up/downconversion mixer. It is fully
assembled and tested at the factory. Standard 50 ?
SMA connectors are included on the EV kit’s input and
output ports to allow quick and easy evaluation on the
test bench.
This document provides a list of test equipment required
to evaluate the device, a straight-forward test procedure
to verify functionality, a description of the EV kit circuit,
the circuit schematic, a bill of materials (BOM) for the kit,
and artwork for each layer of the PC board.
o
o
o
o
o
o
o
o
o
o
o
o
o
Fully Assembled and Tested
50 ? SMA Connectors on Input and Output Ports
1700MHz to 3000MHz RF Frequency Range
1900MHz to 3000MHz LO Frequency Range
DC to 350MHz IF Frequency Range
7.5dB Conversion Loss
+31dBm Input IP3 (Downconversion)
+23dBm Input 1dB Compression Point
7.8dB Noise Figure
Integrated LO Buffer
Integrated RF and LO Baluns
Low -3dBm to +6dBm LO Drive
Built-In SPDT LO Switch with 43dB LO1 to LO2
Isolation and 50ns Switching Time
o External Current-Setting Resistor Provides Option
for Operating Mixer in Reduced-Power/Reduced-
Performance Mode
Component Suppliers
Ordering Information
SUPPLIER
Johnson
M/A-Com
PHONE
507-833-8822
800-366-2266
WEBSITE
www.johnsoncomponents.com
www.macom.com
PART
MAX2043EVKIT
*EP = Exposed paddle.
TEMP RANGE
-40°C to +85°C
IC PACKAGE
36 Thin QFN-EP*
Murata 770-436-1300 www.murata.com
Note: Indicate that you are using the MAX2043 when contact-
ing these component suppliers.
Component List
DESIGNATION
C1
C2, C4, C6, C8
C3
QTY
1
4
0
DESCRIPTION
4pF ±0.25pF, 50V C0G ceramic
capacitor (0402)
Murata GRM1555C1H4R0C
22pF ±5%, 50V C0G ceramic
capacitors (0402)
Murata GRM1555C1H220J
Not installed (0603)
DESIGNATION
R1
R2
T1
TP1
QTY
1
1
1
1
DESCRIPTION
357 ? ±1% resistor (0402)
47k ? ±5% resistor (0603)
1:1 transformer (50:50)
M/A-COM MABAES0029
Large test point for 0.062in PC board
(red)
Mouser 151-107-RC or equivalent
0.01μF ±10%, 25V X7R ceramic
Large test point for 0.062in PC board
C5, C7, C9
3
capacitors (0402)
TP2
1
(black)
Murata GRM155R71E103K
PC board edge-mount SMA RF
Mouser 151-103-RC or equivalent
Large test point for 0.062in PC board
J1–J4
4
connectors (flat-tab launch)
TP3
1
(white)
Johnson 142-0741-856
Mouser 151-101-RC or equivalent
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
1
